導軌型號

配用鏈條型號

B

H

b1

b2

h1

h2

PDF 圖紙

DXF圖紙

mm

mm

mm

mm

mm

mm

LD06B-1-S-TS

06B-1

20

10

3.8

13.0

1.5

1.1

請咨詢

請咨詢

LD083-1-S-TS

083-1

20

10

3.0

12.4

1.6

1.4

LD085-1-S-TS

085-1

22

10

4.5

15.1

2.2

1.6

LD08B-1-S-TS

08B-1

25

15

5.7

16.3

2.2

1.6

LD10B-1-S-TS

10B-1

28

15

7.4

19.2

2.6

2.1

LD12B-1-S-TS

12B-1

30

20

9.2

21.8

2.4

2.8

LD16B-1-S-TS

16B-1

42

25

15.0

35.0

3.5

3.3

LD20B-1-S-TS

20B-1

50

25

16.8

40.0

4.2

4.0

LD35-1-S-TS

35-1

20

10

3.7

11.0

2.3

0.7

LD40-1-S-TS

40-1

25

10

6.3

15.5

2.4

1.8

LD50-1-S-TS

50-1

30

15

7.5

19.5

2.8

2.3

LD60-1-S-TS

60-1

35

15

10.1

24.4

3.5

2.7

LD80-1-S-TS

80-1

40

20

12.6

31.3

4.7

3.6

LD100-1-S-TS

100-1

50

25

15.1

38.4

6.4

4.3

LD120-1-S-TS

120-1

60

30

20.2

48.6

8.0

5.0

LD140-1-S-TS

140-1

70

30

20.2

52.5

9.7

5.7

LD160-1-S-TS

160-1

80

35

25.2

62.5

10.3

6.4
